Description
2009-14 Volkswagen Jetta / Golf / Beetle & Audi A3 2.0 TDI CJAA / CBEA Turbo Gasket Kit
Replacing the turbo on your 2.0L TDI CBEA or CJAA and or maybe upgrading to a CR170 or Hybrid GT22 turbo, don't re-use your old gaskets and hardware. With first hand experience, re-using gaskets will lead to an exhaust leak and poor performance or weird squealing sounds requiring you to do the job a second time. This kit includes the majority of items you need to get your TDI back on the road.
Features and Benefits:
- OE Grade: OE grade gaskets and hardware for a factory install
- Easy Install: Ensure you have majority of what you need to re-install your turbo
- Cost Effective Pricing: Compared to the OE or other Aftermarket companies
What's In the Box:
- (1) Turbo Manifold to Head MLS Gasket OE# 03L253039B | 03L-253-039-B
- (10) Copper Pinch Stud Nuts OE# N90200201
- (1) Turbo to Downpipe Gasket OE# 1K0253115T | 7H0253115B | 1K0-253-115-T | 7H0-253-115-B
- (1) Down Pipe Clamp OE# 04L253725B | 04L-253-725-B | 1K0253725 | 1K0-253-725
- (1) Oil Drain Pipe Gasket OE# 03L145757Q | 03L-145-757-Q | 03G145757A
- (1) EGR Pipe Gasket OE# 038131547A | 038-131-547-A | 03L131547D
- (8) Turbo Manifold Studs OE# N0145555
- (2) EGR Pipe to Turbo Studs
- (2) Turbo Outlet Dampener Screws OE# N91117502
- (2) Turbo Inlet EGR Adapter Screws OE# N91032702
- (2) Oil Return Line Bottom O-rings OE# WHT001965
- (1) Intake to Turbo Adapter Seal OE# 3C0129646 | 3C0-129-646
Verified Fitment:
Audi A3
- 2010 Audi A3 TDI 2.0 CBEA
- 2011 Audi A3 TDI 2.0 CBEA
- 2012 Audi A3 TDI 2.0 CBEA
- 2013 Audi A3 TDI 2.0 CBEA
Volkswagen Golf
- 2010 Volkswagen Golf TDI 2.0 CJAA
- 2011 Volkswagen Golf TDI 2.0 CJAA
- 2012 Volkswagen Golf TDI 2.0 CJAA
- 2013 Volkswagen Golf TDI 2.0 CJAA
- 2014 Volkswagen Golf TDI 2.0 CJAA
Volkswagen Jetta
- 2009 Volkswagen Jetta TDI 2.0 CBEA
- 2010 Volkswagen Jetta TDI 2.0 CJAA
- 2011 Volkswagen Jetta TDI 2.0 CJAA
- 2012 Volkswagen Jetta TDI 2.0 CJAA
- 2013 Volkswagen Jetta TDI 2.0 CJAA
- 2014 Volkswagen Jetta TDI 2.0 CJAA
Volkswagen Beetle:
- 2013 Volkswagen Beetle TDI 2.0 CJAA
- 2014 Volkswagen Beetle TDI 2.0 CJAA
Interchanges
FCP Euro KIT-CJAATDITRBINSKT | KERMA CRTIK | ELRING 005.267 / 005267 | AJUSA JTC11576
Fit's these turbos:
1570848 ,1570882 ,4069179 ,4709077 ,40010117 ,1700701416 ,1700702321 ,8299297578 ,8299298684 ,53039700129 ,53039700130 ,53039700137 ,53039700169 ,53039700207 ,53039700208 ,53039880129 ,53039880130 ,53039880137 ,53039880169 ,53039880207 ,53039880208 ,030TC20023000 ,030TC20023100 ,03L253010 ,03L-253-010 ,03L253010D ,03L-253-010-D ,03L253010V ,03L-253-010-V ,03L253010X ,03L-253-010-X ,03L253016G ,03L-253-016-G ,03L253016K ,03L-253-016-K ,03L253016KV ,03L-253-016-KV ,03L253016KX ,03L-253-016-KX ,03L253019C ,03L-253-019-C ,03L253019E ,03L-253-019-E ,03L253019EV ,03L-253-019-EV ,03L253019EX ,03L-253-019-EX ,03L253019K ,03L-253-019-K ,03L253019M ,03L-253-019-M ,03L253019N ,03L-253-019-N ,03L253019NV ,03L-253-019-NV ,03L253019NX ,03L-253-019-NX ,03L253056 ,03L-253-056 ,03L253056C ,03L-253-056-C ,03L253056V ,03L-253-056-V ,03L253056X ,03L-253-056-X ,100TBC529 ,100TBC529S ,11802G ,170-070-1416 ,170-070-2321 ,2N425 ,2N-425 ,2T421 ,2T-421 ,5303-970-0129 ,5303-970-0130 ,5303-970-0137 ,5303-970-0169 ,5303-970-0207 ,5303-970-0208 ,5303-988-0129 ,5303-988-0130 ,5303-988-0137 ,5303-988-0169 ,5303-988-0207 ,5303-988-0208 ,829-929-7578 ,829-929-8684 ,BWT31330 ,K1430104N ,K8430101R ,TBC529 ,TBC529S ,X406A ,X-406A
