Name: 2014-2022 Sprinter 2.1 OM651 Turbo Gasket Kit | HP/LP Install Kit | ART Turbos
Brand: ART Turbos
SKU: ART-TIK00028
Price: 88.13 USD
Availability: InStock

2014-2022 Sprinter 2.1 OM651 Turbo Gasket Kit | HP/LP Install Kit | ART Turbos

(No reviews yet) Write a Review

$88.13

SKU:

ART-TIK00028

Condition:

New

Availability:

Ships same day: If ordered by 2pm Central Standard Time

Weight:

1.50 LBS

Shipping:

Calculated at Checkout

Description

Turbo Gasket Kit for 2014-2022 Mercedes & Freightliner Sprinter Vans with the 2.1L OM651 engine and High Pressure / Low Pressure Turbo Assembly

The OM651 2.1L Sprinter uses a sequential twin-turbo setup, with a High Pressure (HP) and Low Pressure (LP) turbo working together — which means twice the gasket surfaces, twice the potential leak points. When either turbo starts leaking oil or exhaust at the manifold, downpipe, or oil return lines, it's rarely just one gasket that's gone; the whole set is usually worn from age and heat cycling.

Replacing the HP and/or LP turbo on a Sprinter is a labor-intensive job — you're already deep into the engine bay pulling manifolds, downpipes, and oil lines. Reusing old, hardened gaskets or corroded hardware at that point is a false economy: it invites a comeback leak and means doing the same labor twice. This kit uses OE-spec MLS and coated gaskets (not generic fiber substitutes) along with OE-grade bolts, clamps, and banjo washers, so every sealing surface disturbed during the turbo swap gets fresh, correctly-speced hardware in one pass.

Fits 2014-2022 Mercedes-Benz and Freightliner Sprinter 2500, 3500, and 3500XD vans equipped with the 2.1L OM651.955 engine.

Features and Benefits:

OE Grade Hardware and Clamps
Gaskets are of OE grade with MLS and Coated Gaskets
One Convenient Kit that Includes all of the components you will need to do the job

Included in the box:

(1) Turbo To Manifold Gasket OE 6510960480 | 651-096-04-80
(1) Oil Return Line Gasket At Block OE# 6510960500 | 651-096-05-00 | A6510960280
(1) Turbo to Downpipe Gasket OE# 0004920981 | 000-492-09-81
(1) Oil Return Pipe Gasket OE# 2740960100 | 274-096-01-00
(1) Turbo to Downpipe Clamp OE# 2034900441 | 203-490-04-41
(1) Oil Feedline O-ring OE# 0239978548 | 023-997-85-48
(2) Oil Return Line Gaskets At Turbo OE# 6510960400 | 651-096-04-00
(3) Turbo to Manifold Bolts OE# 0009906803 | 000-990-68-03
(7) Copper Mounting Bolts For Lines OE# N910143006001| AN910143006001 | 910-143-00-60-01
(4) Banjo Washers OE# AN007603010406 | N007603010406 | 007-603-01-04-06
